YSK Clasp Locking |
|
| |
|
|
The locking method utilize the elasticity of steel itself, it is compelled to lock with axical locking. This product is designed for bad work surroundings and easy let-off nut. It'sability of locking is 3 times as stronger as traditional locking, this is its advantage.For the locking method of YSK because of the miss of assembly,it can not assure the vertical deflection between ground end and threads, that is the defect of this type. |
| |
|
|
 |
Material Composition: SCM440 |
|
Thread Precision:ISO 4H |
|
Ground end squarencess:0.005mm |
|
Hardness:HRC28 °~32° |
|
| |
|
|
 |
| |
|
|
| |
|
|
Thread |
D |
h |
g |
n-m x L |
n |
b |
c |
MAX.Nm |
|
| YSK
M16x1.5 |
34
|
18
|
29 |
4-M4x12
|
4
|
4
|
24
|
3.5
|
| YSK
M17x1 |
37 |
32 |
26 |
| YSK
M18x1.5 |
38 |
33 |
28 |
| YSK
M20x1 |
40 |
35 |
30 |
| YSK
M20x1.5 |
| YSK
M22x1.5 |
42 |
37 |
32 |
| YSK
M24x1.5 |
44 |
39 |
34 |
| YSK
M25x1.5 |
45 |
20
|
40 |
4-M4x14 |
5
|
35 |
| YSK
M26x1.5 |
| YSK
M28x1.5 |
46 |
43 |
37 |
| YSK
M30x1.5 |
48 |
45 |
39 |
| YSK
M32x1.5 |
50 |
22
|
47 |
4-M4x16
|
41 |
| YSK
M35x1.5 |
53 |
50 |
44 |
| YSK
M38x1.5 |
56 |
53 |
47 |
| YSK
M40x1.5 |
58 |
55 |
49 |
| YSK
M42x1.5 |
60 |
51 |
| YSK
M45x1.5 |
68 |
63 |
6-M4x18 |
6 |
6
|
57 |
| YSK
M48x1.5 |
69 |
25
|
65 |
58 |
| YSK
M50x1.5 |
70 |
66 |
60 |
| YSK
M52x1.5 |
72 |
68 |
62 |
| YSK
M55x1.5 |
75 |
71 |
65 |
| YSK
M55x2 |
| YSK
M58x1.5 |
82 |
26 |
77 |
6-M5x20 |
70 |
4.5 |
| YSK
M60x1.5 |
84 |
79 |
72 |
| YSK
M60x2 |
| YSK
M62x1.5 |
86 |
28
|
82 |
75 |
| YSK
M65x1.5 |
88 |
84 |
77 |
| YSK
M65x2 |
| YSK
M68x1.5 |
93 |
87 |
7 |
80 |
| YSK
M70x1.5 |
95
|
89 |
82
|
| YSK
M70x2 |
| YSK
M72x1.5 |
97 |
91 |
84 |
| YSK
M75x1.5 |
100 |
94 |
87 |
| YSK
M75x2 |
| YSK
M80x2 |
110 |
32 |
103 |
6-M6x22
|
8 |
95 |
8 |
| YSK
M85x2 |
115 |
108 |
100 |
| YSK
M90x2 |
120 |
113 |
105 |
| YSK
M95x2 |
125 |
118 |
110 |
| YSK
M100x2 |
130 |
123 |
115 |
| YSK
M105x2 |
135 |
128 |
120 |
| YSK
M110x2 |
140 |
133 |
125 |
| YSK
M115x2 |
145 |
34 |
137 |
130 |
| YSK
M120x2 |
155 |
36
|
146 |
6-M6x25
|
136 |
| YSK
M125x2 |
160 |
150 |
140 |
| YSK
M130x2 |
165 |
155 |
148 |
| YSK
M140x2 |
180 |
38 |
168 |
8-M6x25 |
8
|
10
|
160 |
| YSK
M150x2 |
190 |
178 |
170 |
| YSK
M160x3 |
205 |
40 |
190 |
8-M8x30 |
178 |
18 |
| YSK
M170x3 |
215 |
200 |
193 |
| YSK
M180x3 |
230 |
213 |
205 |
| YSK
M190x3 |
240 |
223 |
215 |
| YSK
M200x3 |
245 |
230 |
223 |
|
| |
| |
|
|
| |
|
|
| |
|
|
| |
 |
|
| |
